Features
1. AK4495S is AKM's 4th generation DAC IC which has capability to decode 32Bit data at rate 768kHz.
2. 192kHz 24Bit stereo DAC supports PCM, HDCD, S/PDIF, FLAC audio input format.
3. Input signal support:
a) coaxial RCA
b) optical Receiver: Japan (24bit/94kHz) or Thailand (24bit/192kHz)
c) USB (16bit/48kHz) or XMOS USB (24bit/192kHz) - support WIN XP, WIN7, WIN8, Linux, Mac OS (auto driver installation)
4. Output signal: coaxial RCA
5. S/N ratio >110dB, dynamic range >120dB and THD < 0.0027%
6. Output Opamps can use NE5534 or AD797 or LM49710
7. Built-in eight independent regulation circuits for providing dedicated power supply to each block.
8. Power requirements: 220/230V AC, 50/60Hz or 110V/115V AC
9. Dimension: 145mm (L) x 54mm (H) x 252mm (D)
Note: For the digital audio from DTS, AC3 disc, the DVD player, it need to be set to PCM output mode before input to this DAC.
USB Driver Download:
