Features
1. Incoporated with high performance DAC PCM1704.
2. Digital receiver IC: CS8414 and using external oscillator to minimize the jitter.
3. DAC-38 accept the input frequency ranging from 44.1kHz-96kHz, audio signal which is equivalent to the quality of DVD audio.
4. Support coaxial and optical inputs, and both coaxial and balance output.
Specification
1. Input format: 44.1kHz- 96kHz, 24bit
2. Digital input: coaxial and optical S/PDIF
3. Anlog output: coaxial and balance, stereo
4. Operating frequency: 20Hz-20kHz
5. S/N ratio: >108dB
6. THD: <0.002%
7. Power supply: 220V or 110V for 50-60Hz
8. Chasis dimension: 405mm(W) x 290mm (D) x100mm (H)
9. Front panel dimension: 430mm(W) x 80mm (H) x 10mm (thickness)
