Operating System CD digital audio system (CD, CD-R)
Frequency Response 20Hz – 20kHz ± 0.2dB
Harmonic Distortion < 0.001% @ 0dB, 1kHz (Typically 0.0005%), < 0.006% @ -30dB, 1kHz, < 0.01% @ 0dB, 20kHz
Intermodulation Distortion < 0.001% @ 0dB (Typically 0.0005%)
S/N Ratio (IHF-A Wtd.) 105 dB
Wow & Flutter Quartz precision
Channel Separation >100 dB @ 1kHz, >80 dB @ 20kHz
Output Voltage 2.0Vrms
Digital Outputs 75 Ohm Coaxial, RCA/ 110 Ohm Balanced AES/EBU, XLR/ Optical, Toslink
D/A Conversion AD1853 Advance Segment, Balanced-Stereo DAC
Resolution/Sampling 24 bits / 192 kHz
Oscillation 3rd Overtone Oscillation
Crystal Super precision, custom made
Jitter <150 psec
Idle Pattern <-115 dB
Stop band Rejection <-78 dB
Power Supply x2 high performance low noise R-core transformers
Power Source 100V – 120V 50Hz / 60Hz / 220V – 240V 50Hz / 60Hz
Power Consumption < 15 W
Dimension 432 x 330 x 70 (W x D x H) mm, 432 x 330 x 80 (including feet)
Weight 9Kg
User Manual
